MSI MPG B650I EDGE WIFI Gaming Desktop Motherboard - AMD B650 Chipset - Socket AM5 - Mini ITX

  • Part: 1469940
  • Model: MPG B650I EDGE WIFI
$389.00

Availability

In Stock

The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style, the MPG series defines the future of gaming fashion.

Extended Heatsink

Extended Heatsink enlarges the surface of heat dissipation, ensuring even high- end processors to run in full speed.

7W/mK Thermal Pad

High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performance.

M.2 Shield Frozr

With double ball bearings fan to keeps M.2 SSDs safe while preventing throttling, making them run faster.

Pump Fan Support

Control watercooling pump speeds for best flow and noise control.

MOSFET Baseplate

Baseplate on the back to keep MOSFET in lower temparature, ensuring better heat dissipation effect.

10-Layer Server Grade PCB

10-layer PCB with 2oz thickened copper provides higher performance and long-lasting system stability without any compromise.

  • General Information
    • Manufacturer
    • MSI
    • Manufacturer Website Address
    • http://au.msi.com
    • Brand Name
    • MSI
    • Product Line
    • MPG
    • Product Type
    • Gaming Desktop Motherboard

  • Processor & Chipset
    • Chipset Manufacturer
    • AMD
    • Chipset Model
    • B650
    • Total Processor Supported
    • 1
    • Processor Socket
    • Socket AM5
    • Processor Supported
    • Ryzen 7
  • Memory
    • Number of Memory Slots
    • 2
    • Memory Form Factor
    • UDIMM
    • DIMM
    • Maximum Memory Supported
    • 64 GB
    • Memory Technology
    • DDR5 SDRAM
    • Memory Speed Supported
    • 6400 MHz
    • 6200 MHz
    • 6000 MHz
    • 5800 MHz
    • 5600 MHz
    • 5400 MHz
    • 5200 MHz
    • 5000 MHz
    • 4800 MHz
    • 6600 MHz
  • I/O Controller
    • Controller Type
    • Serial ATA/600
    • RAID Supported
    • Yes
    • RAID Levels
    • 0
    • 1
    • 10
  • Video
    • Onboard Video
    • CPU Dependent Video
  • Audio
    • Audio Channels
    • 7.1
  • Network & Communication
    • Bluetooth
    • Yes
    • Bluetooth Standard
    • Bluetooth 5.2
    • Gigabit Ethernet
    • Yes
    • 2.5Gigabit Ethernet
    • Yes
    • Wireless LAN
    • Yes
    • Wireless LAN Standard
    • IEEE 802.11 a/b/g/n/ac/ax
  • I/O Expansions
    • Total Number of Expansion Slots
    • 1.0
    • PCI Express Standard
    • PCI Express 4.0
    • Total Number of PCI Express Slots
    • 1
    • Number of PCI Express x16 Slots
    • 1
  • Interfaces/Ports
    • Total Number of USB Ports
    • 6
    • Number of USB 3.2 Gen 1 Type-A Ports
    • 2
    • Number of USB 3.2 Gen 2 Type-A Ports
    • 3
    • HDMI
    • Yes
    • HDMI Version
    • 2.1
    • Number of Network (RJ-45) Ports
    • 1
  • Onboard Interfaces
    • Number of SATA Interfaces
    • 4
    • Number of M.2 Interfaces
    • 2
    • Total Number of Onboard USB Ports
    • 5
    • Number of Onboard USB 2.0 Ports
    • 2
  • Physical Characteristics
    • Form Factor
    • Mini ITX
    • Width
    • 170 mm
    • Depth
    • 170 mm
  • Miscellaneous
    • Brand Compatibility
    • AMD
