APC by Schneider Electric NetShelter AP8958EU3 PDU

  • Part: 1028503
  • Model: AP8958EU3
$2,014.00

Availability

Out of Stock

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com.au
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • NetShelter
    • Product Series
    • Switched
    • Product Type
    • PDU

APC Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring. Remote outlet level controls allow power on/off functionality for power cycling to remotely reboot equipment and restrict unauthorized use of individual outlets. Power sequencing time delays allow users to define the order in which to power up or down attached equipment to avoid circuit overload. Current metering provides real-time remote monitoring of connected loads with user-defined alarms to warn of potential circuit overloads. Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, Command Line Interface, or Telnet Interfaces which are complimented by APC Centralized Management platforms using InfraStruxure Central, Operations, Capacity, and Energy Efficiency. New AP8000 series Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles.

  • Warranty
    • Limited Warranty
    • 2 Year

  • Technical Information
    • PDU Type
    • Switched
    • Receptacle Type
    • IEC 60320 C19
    • IEC 60320 C13
    • Receptacle Detail
    • 1 x IEC 60320 C19
    • 7 x IEC 60320 C13
  • Power Description
    • Input Voltage
    • 230 V AC
    • Input Voltage Range
    • 200 V AC - 230 V AC
    • Output Voltage
    • 200 V AC
    • 208 V AC
    • 230 V AC
  • Management
    • Management
    • Protocols:

      • Web
      • SNMP
      • Telnet
      • Command Line Interface
  • Physical Characteristics
    • Mount Type
    • Rack-mountable
    • Number of Cord/Cable
    • 1
    • Height
    • 988 mm
    • Width
    • 56 mm
    • Depth
    • 46 mm
    • Weight (Approximate)
    • 3.23 kg
  • Miscellaneous
    • Package Contents
      • Switched Rack AP8958EU3 8-Outlets PDU
      • Installation Guide
      • Locking Input Power Cord
      • Rack Mounting Brackets
      • Safety Guide
      • Sample Locking IEC Power Cord
      • Serial Configuration Cable
    • Additional Information
    • Input Receptacle: IEC 309 16A 2P+E

    • Environmentally Friendly
    • Yes
